Dial Indicator

Indicator Features:

• Range: 0-10mm
• Resolution: 0.01mm
• Accuracy: ± 0.013mm
• Accuracy 1/10 rev: 0.005mm
• Accuracy 1 rev: 0.010mm
• Repeatability: 0.003mm
• Measuring Force: 1.4N or less
• Carbide tipped, thread: M 2.5 x 0.45 mm
• MPN: 2046A-09
• Brand: Mitutoyo

Basic Features:

• Range: 0-5mm
• Graduations: 0.001mm
• Range/Rev: 0.2mm
• Dial Reading: 0-100-0
• Type: with lug
• Accuracy: +/- 0.010mm
• Measuring Force: 1.5N or less
• Stem/Shank: 8mm
• Contact Point: M2.5 x 0.45 Thread
• Type: ISO/JIS
• Shockproof Type: No
• Waterproof Type: No
• Long Stem Type: No
• Jeweled Bearing Type: Yes
• Double Scale Spacing Type: No
• With Coaxial Revolution Counter Type: No
• Reverse Reading Type: No
• With Damper at Lowest Rest Point Type: No
• Model No: Mitutoyo 2119A-10

Basic Features:

• Model No: Mitutoyo  511-210-20
• Range: 6 – 10mm
• Resolution: 0.001mm
• Accuracy:  ± 2µm (0.002mm)
• Measuring Depth: 50mm
• Measuring Force: 2N or less
• Stroke of contact point: 0.5mm
• No. of Anvils: 9
• Analogue
• Metric

Basic Features:

• Model No: Mitutoyo 511-212-20
• Range: 0.24-0.4″
• Resolution: 0.0001″
• Accuracy: ± 5 µm (0.005mm)
• Repeatability: 0.002mm
• Measuring Depth: 2″
• No. of Anvils: 9
• Analog
• Inch

Basic Features:

• Range: 0.14mm
• Resolution: 0.001mm
• Accuracy: ± 0.003mm
• MPE any 10 scale divisions: ±0.002mm
• MPE Measuring range: 0.003mm
• Hysteresis: 0.002mm
• Repeatability: 0.001mm
• Scale: 0-70-0
• Measuring Force: 0.3N or less
• Contact Point: Thread M 1.7 x 0.35 mm
• Mitutoyo: 513-401-10E

Basic Features:

• Range: 0.14mm
• Resolution: 0.001mm
• MPE any 10 scale divisions: ±0.002mm
• MPE Measuring range: 0.003mm
• Hysteresis: 0.002mm
• Repeatability: 0.001mm
• Scale: 0-70-0
• Measuring Force: 0.3N or less
• Contact point: M 1.7 x 0.35 mm
• Metric
• Model No: Mitutoyo 513-471-10E

Detailed Description

This Mitutoyo standard model of indicator is reliable and easy to use. The ABSOLUTE Digimatic Indicator ID-S offers you the following benefits:

• The ABSOLUTE sensor means you don‘t have to carry out origin setting every time you power it on, saving you time and hassle.
• You can access all functions by using the large, user-friendly buttons on the front of the indicator.
• Large character height of 9 mm provides good readability.
• Exceptional battery life.
• Data Output – YES
• Origin reset is not required even when data is re-displayed after a disappearance due to insufficient illumination during use

Basic Features

• Model No: Mitutoyo 547-301A
• Range:0-10mm
• Resolution: 0.01mm
• Accuracy: ± 0.020mm
• Parallelism: 0.01mm
• Measuring force: 1.5N or less
• Max measuring depth: 30mm
• SPC data output – YES
• Ceramic-tipped contact points
• Scale: Capacitance type ABSOLUTE linear encoder
• Max response speed: Unlimited
• Switchable counting direction
• Metric

Basic Features

• Model No: Mitutoyo 547-360A
• Range:0-10mm
• Resolution: 0.01mm
• Accuracy: ± 0.01mm
• Measuring force: 1.5N or less
• Max measuring depth: 20.5mm
• SPC data output – YES
• Scale: Capacitance type ABSOLUTE linear encoder
• Switchable counting direction
• Metric

Basic Features

• Model No: Mitutoyo 7301A
•  Range: 0-10mm
•  Graduations: 0.01mm
•  Accuracy: +/- 0.015mm
•  Measuring Force: 1.4N or less
• Remarks: Standard
• Spindle/Anvil Material: Ceramic

Basic Features

• Model No: Mitutoyo 7305A
• Range: 0-20mm
• Resolution: 0.01mm
• Accuracy: ± 0.020mm
• Parallelism: 0.005mm
• Measuring force: 2N or less
• Max measuring depth: 30mm
• Contact point: Ceramic disc, M 2.5 x 0.45 mm
• Metric
