Detailed Description
This ABSOLUTE Digimatic Thickness Gauge enables you to measure film, paper, etc.. with flat contact points with SPC data output.
-21%
Dial Indicator, Test, Measure & Inspect
Mitutoyo 547-300A (0.01mm/0.0005″) ABSOLUTE Digimatic Thickness Gauge 0-10mm (0-0.4″)
Basic Features
- Model No: Mitutoyo 547-300A
- Range:0-10mm (0-0.4″)
- Resolution: 0.01mm (0.0005″)
- Accuracy: ± 0.020mm (0.001″)
- Parallelism: 0.01mm (0.0005″)
- Measuring force: 1.5N or less
- Max measuring depth: 30mm
- SPC Digimatic data output- YES
- Ceramic-tipped contact points
- Scale: Capacitance type ABSOLUTE linear encoder
- Max response speed: Unlimited
- Switchable counting direction
- Inch/Metric
₹27,650.00 ₹35,120.00 Inc GST
Based on 0 reviews
Be the first to review “Mitutoyo 547-300A (0.01mm/0.0005″) ABSOLUTE Digimatic Thickness Gauge 0-10mm (0-0.4″)”
