Product Detailed Description:
-24%
Micrometer, Test, Measure & Inspect
Mitutoyo 350-251-30 (0.001mm) Digital Micrometer Head with 10mm Plain Stem 0-25mm (Copy)
Micrometer Head Features:
- Model No: Mitutoyo 350-251-30
- Range: 0-25mm
- Resolution: 0.001mm
- Accuracy: ± 0.002mm
- Stem: Plain, Ø 10mm
- Spindle Pitch: 0.5mm
- Measuring spindle: With spindle lock, ø 6.35mm
- Carbide tipped measuring face
- ABS / INC Zero
- Power: 1x SR44 battery
- Data output- YES
- Metric
$195.32 $257.09 Inc GST
Product Detailed Description:
Specifications:
- Range = 0-25mm
- Accuracy = +/- 2µm
- Resolution = 0.001mm
- Stem diameter = 10mm
- Stem type = Plain
- Measuring force = 5-10N
- Spindle face = Flat, carbide tip
- Data Output = Yes, use water resistant SPC cable with data switch.
- Display = LCD
- Battery = SR44, battery life approximately 2 year under normal use.
- Functions = data output, function lock, 2 presets, low voltage alarm, counting value composition error alarm.
- Weight: 230 gms approx
